Pallet Forks

Features

  • Four models to choose from
  • From 3,307 Ib to 6,613 lb capacity
  • Automatically levels load
  • Telescopic vertical riser and adjustable sliding forks
  • Light weight maximizes lift capacity
Request a Quote

Maximize your lift capacity with our lightweight MBRA-E crane forks

The Boscaro crane forks are auto leveling thanks to an internal spring system. Other valuable features include adjustable width and height, as well as a fork length of 4’ which increases stability and safety. All of our crane forks either meet or surpass ASME protocol and are therefore certified for use within North America. The forks are tagged and come with the necessary certifications and supporting paperwork for ASME compliance across all of North America. If you have any questions, don’t hesitate to call – we have a highly qualified staff of technical sales reps ready to answer your questions.
Other Forks

Metric or Imperial Switch

Model Capacity Dimensions Weight
A B C D E G L M
MBRA-15E-12* 3,300 lb1,500 kg 3′ 1″0.95 m 3′ 3″1.00 m 1′ 4″0.40 m 5′ 0″1.10 m 6′ 9″1.64 m 4’0″1.2 m 1.3″3.0 cm 4″9.0 cm 410 lb140 kg
MBRA-20E-12* 4,400 lb2,000 kg 3′ 1″0.95 m 3′ 3″1.00 m 1′ 4″0.40 m 5′ 0″1.10 m 6′ 9″1.64 m 4′ 0″1.2 m 1.3″3.5 cm 4.7″10.0 cm 440 lb155 kg
MBRA-25E-12 5,500 lb2,500 kg 3′ 1″0.95 m 3′ 3″1.00 m 1′ 4″0.40 m 3′ 6″1.10 m 5′ 4″1.64 m 4′ 0″1.2 m 1.4″3.5 cm 4.7″12.0 cm 575 lb260 kg
MBRA-30E-12 6,613 lb3,000 kg 3′ 1″0.95 m 3′ 3″1.00 m 1′ 4″0.40 m 3′ 6″1.10 m 5′ 4″1.64 m 4′ 0″1.2 m 1.4″3.5 cm 4.7″12.0 cm 675 lb305 kg
*3’3 fork length models also available.
